CLASS ROD SEALTYPE SECTION MATERIAL HARDNESS SHORE A ADAPTABLE TEMP (oC) PRESSURE KG/CM2
SYMME-TRICAL SEAL UN GM-90 90±2 -35 ~ +100 210
350
D-6 GM-90 90±2 -35 ~ +100 400
PISTON SEAL D-1 GM-95 95±2 -35 ~ +100 420
HEAVY DUTY PISTON SEAL D-1S A-95 95±2 ~35+120 700
ROD SEAL D-2 GM-95 95±2 -35 ~ +100 420
HEAVY DUTY D-2S A-95 95±2 ~35+120 700
ROD SEAL D-3 GM-90 95±2 -35 ~ +100 420
CLASS TYPE SECTION MATERIAL HARDNESS SHORE A ADAPTABLE TEMP (oC) PRESSURE KG/CM2
PISTON SEAL D-8 GM-95 95±2 -35 ~ +100 　
DUST SEAL D-9 GM-95 95±2 -35 ~ +100
BUFFER RING D-10 GM-95 95±2 -35 ~ +100
DUST SEAL DH GM-90 90±2 -35 ~ +100
DH-03 GM-90 90±2 -35 ~ +100
DH-04 GM-90 90±2 -35 ~ +100
DH-05 GM-90 90±2 -35 ~ +100
DH-07 GM-90 90±2 -35 ~ +100 　
CLASS TYPE SECTION MATERIAL HARDNESS SHORE A ADAPTABLE TEMP (oC) PRESSURE KG/CM2
METAL CLAD WIPERS ME-1 GK-90 90±2 -35 ~ +90 　
ME-1N GK-90 90±2 -35 ~ +90
ME-2 GK-90 90±2 -35 ~ +90
ME-3 GK-90 90±2 -35 ~ +90
ME-4 GK-90 90±2 -35 ~ +90
ME-5 GK-90 90±2 -35 ~ +90
ME-8 GK-95 90±2 -35 ~ +90
